Part No Part Description


I 001 - Valve Body
I 002 - Valve Spring
I 003 - Exhaust Valve
I 004 - Valve Guide
I 005 - Valve Guide Inner O-ring
I 006 - Valve Guide/Bolt O-Ring
I 007 - Valve Retainer Screw/Velocity Adjuster Retaining Screw
I 008 - Split Washer (Large)
I 009 - Trigger
I 010 - Saftey Catch
I 011 - Safty Ball
I 012 - Saftey Spring
I 013 - Frame Retainer Screw Front
I 014 - Dowel Pin 1/8 X 5/8
I 015 - Frame Retainer Screw Rear
I 016 - Sear
I 017 - Grip
I 018 - Bottom Line
I 019 - Hose, High Pressure
I 020 - Elbow
I 021 - Grip Retainer Screw
I 022 - Hammer O-Ring
I 023 - Hammer
I 024 - Bumper
I 025 - Sear Spring
I 026 - Main Spring
I 027 - Spring Guide
I 028 - Velocity Adjuster Body
I 029 - Velocity Adjuster Insert
I 030 - Velocity Adjuster Insert O-Ring
I 031 - Top Cap
I 032 - Bolt Plunger
I 033 - Top Cap Retainer Screw
I 034 - Cocking Handle
I 035 - Ball Retainer (Nitrile)
I 036 - Retainer Cover Plate
I 037 - Split Washer (Small)
I 038 - Ball Retainer Cover Screw
I 039 - Barrel
I 040 - Trigger Spring
I 041 - Body
I 042 - Bolt
I 043 - Grip Frame
I 044 - Flat Washer








































Parts kits as follows

INFER0120 PART KIT SMALL NYLON
INFER0005 - BS013 / 70N O-Ring Valve Guide Inner X1
INFER0006 - BS015 / 70N O-Ring Valve Guide Outer/ Barrel X2
INFER0022 - Red O-Ring BS016 / 70 Hammer X 1
INFER0026 - Main Spring X 1
INFER0030 - BS011 / 70N 'O ring' Vel' Adj' Insert X1
INFER0035 - Ball Retainer (Nitrile) X1
INFER1003 - Exhaust Valve Comp Nylon X1

INFER0120U PARTS KIT - SMALL (URATHANE VALVE)
INFER0005 - BS013 / 70N O-Ring Valve Guide Inner X1
INFER0006 - BS015 / 70N O-Ring Valve Guide Outer/ Barrel X2
INFER0022 - Red O-Ring BS016 / 70 Hammer X 1
INFER0026 - Main Spring X 1
INFER0030 - BS011 / 70N 'O ring' Vel' Adj' Insert X1
INFER0035 - Ball Retainer (Nitrile) X1
INFER1071 - Exhaust Vlve Comp Urathane x1

INFER0125 Parts Kit (Large)
INFER0002 - Valve Spring x1
INFER0005 - BS013 / 70N O-Ring  Valve Guide Inner x1
INFER0006 - BS015 / 70N O-Ring Valve Guide Outer/ Barrel x2
INFER0007 - Valve Retainer Screw/Vel 10-32unf x 3/8 x4
INFER0008 - Split Washer (Large) 10NF x6
INFER0013 - Frame Retainer Screw Front 10-32unf x 7/8 skt btn hd x1
INFER0014 - Dowel Pin 1/8 X 5/8 x2
INFER0015 - Frame Retainer Screw Rear (front on stp) 10-32unfx1
INFER0022 - Red O-Ring BS016 / 70 Hammer x2
INFER0025 - Sear Spring x1
INFER0026 - Main Spring x1
INFER0030 - BS011 / 70N 'O ring' Vel' Adj' Insert x1
INFER0035 - Ball Retainer (Nitrile) x1
INFER0037 - Split Washer (Small) 6NF (M 3.5) x2
INFER0038 - Ball Retainer Cover Screw 6-32unc x 3/16 btn skt x2
INFER0040 - Trigger Spring x1
INFER0044 - Flat Washer M5 Form A x2
INFER1003 - Exhaust Valve Comp Nylon x1

INFER0130 Parts kit (Field)
INFER0002 - Valve Spring x2
INFER0004 - VALVE GUIDE x1
INFER0005 - BS013 / 70N O-Ring  Valve Guide Inner x10
INFER0006 - BS015 / 70N O-Ring Valve Guide Outer/ Barrel x 20
INFER0007 - Valve Retainer Screw/Vel 10-32unf x 3/8 x 20
INFER0008 - Split Washer (Large) 10N x 20
INFER0010 - Safety Catch x5
INFER0011 - Safety Ball 3/32 CHROME BALL BEARING x10
INFER0012 - Safety Spring x10
INFER0013 - Frame Retainer Screw Front 10-32unf x 7/8 skt btn hd x5
INFER0014 - Dowel Pin 1/8 X 5/8 x4
INFER0015 - Frame Retainer Screw Rear (front on stp) 10-32unf x5
INFER0016 - Sear (Cold Black) x1
INFER0019 - "Hose, High Pressure 11.5" x1
INFER0020 - Elbow x1
INFER0022 - Red O-Ring BS016 / 70 Hammer x10
INFER0025 - Sear Spring x2
INFER0026 - Main Spring x5
INFER0030 - BS011 / 70N 'O ring' Vel' Adj' Insert x10
INFER0032 - Bolt Plunger x1
INFER0034 - Cocking Handle x10
INFER0035 - Ball Retainer (Nitrile) x20
INFER0036 - Retainer Cover Plate x2
INFER0037 - Split Washer (Small) 6NF (M 3.5) x20
INFER0038 - Ball Retainer Cover Screw 6-32unc x 3/16 btn skt  x10
INFER0040 - Trigger Spring x2
INFER0044 - Flat Washer M5 Form A x10
INFER1003 - Exhaust Valve Comp Nylon x10
INFER1040 - Hammer Assembly x1

INFER1110 Parts Kit (Free) Nylon
INFER1110 AND 1115 ARE FREE KITS AND WILL GET 1 PER GUN IF GUN IS BROUGHT
INFER0005 - BS013 / 70N O-Ring  Valve Guide Inner x1
INFER0006 - BS015 / 70N O-Ring Valve Guide Outer/ Barrel x2
INFER0022 - Red O-Ring BS016 / 70 Hammer x1
INFER1003 - Exhaust Vlve Comp Nylon x1

INFER1115 Parts Kit (Free) Urathane
INFER0005 - BS013 / 70N O-Ring  Valve Guide Inner x1
INFER0006 - BS015 / 70N O-Ring Valve Guide Outer/ Barrel x2
INFER0022 - Red O-Ring BS016 / 70 Hammer x1
INFER1071 - Exhaust Vlve Comp Urathane x1
